OGS 10
OGS10, ideal for both new installations and retrofit projects.
Electronic keypad locking solutions for lockers, cabinets and drawers, providing secure and convenient lockers management for new installations and retrofit alike.
Key Features
Easy Retrofit Installation
Replace existing mechanical locks quickly and cost-effectively, without modifying your furniture or lockers.
Universal Compatibility
Compatible with a wide range of lock types, door materials, cylinder configurations and furniture applications.
Flexible Installation
Supports both vertical and horizontal mounting.
Extended Battery Life
Powered by two CR2032 batteries, providing up to 6 years of operation with minimal maintenance requirements.
Flexible User Modes
Supports free-use, dedicated-use
Secure Emergency Access
Master code and mechanical emergency key ensure continuous access and simplified maintenance.
Durable Construction
Engineered for demanding, high-frequency environments with robust and reliable components.
Intuitive User Experience
Easy-to-use keypad interface with LED indicators and buzzer feedback for clear user interaction.
UNO Line Compatibility
Compatible with UNO Line mechanical lock configurations through cylinder replacement, enabling a smooth upgrade path to electronic locking.
Technical Specifications
| Authentication | PIN Code |
| User Code Length | 4, 5 or 6 digits |
| Modes | Free, Dedicated |
| Notifications | LED + Buzzer |
| Power Supply | 2 × CR2032 batteries |
| Battery Life | Up to 6 years / 10,000 cycles |
| Dimensions | 111 × 26 × 15.5 mm |
| Weight | 215 g |
| Installation | Vertical or Horizontal |
| Door Thickness (Lockers) | 6–20 mm |
| Door Thickness (Furniture) | 16–20 mm |
| Operating Temperature | 0 °C to +50 °C |
Finishes
OGS 10 Vertical
OGS 10 Horizontal
Options
Mechanical Emergency Opening Key
Provides a secure override solution for maintenance personnel and facility managers.
Update
OGS 10 is fully compatible with OJMAR UNO Line mechanical lock configurations. By simply replacing the cylinder, facilities can upgrade to electronic locking without changing doors, lockers or furniture, reducing installation time, costs and disruption.
